Mechanic: Lacking Information · 1:21am Aug 20th, 2019

For this one, we’re gonna talk about a vehicle I should know well: a Dodge Caravan.


Now Kiss

This particular vehicle didn’t have functioning air conditioning.


All in all, it was a basic Caravan. 2005 or thereabouts, it had rear AC and dual zone in the front, which was the most common configuration--all three of mine are set up that way. It had an overhead console with the display, which is important later.

I didn’t do the initial diagnosis on it. My manager had looked at it. He told me that he’d checked the refrigerant pressure with the AC machine, and it was sufficient for the AC compressor on the vehicle to turn on. He’d also hooked the scan tool up to it, and the sensor on the vehicle also indicated sufficient pressure.

A lot of computer controlled components can be turned on and off with the scan tool, and such was the case with the AC compressor on these. He said that the scan tool would NOT turn on the AC, but if he jumpered the relay, the compressor did come on. He said that when he did, he could feel cold air blowing through the vents, and he also said that when he did the cooling fan did not come on.

There were no useful codes in either the engine control module, nor were there useful codes in the HVAC module.

So what we had, in short, was a vehicle that simply did not want to turn the AC on.


I’ll step away from the vehicle for just a second, to give you a basic, generic rundown of how modern vehicles control the AC system. Just the real basics.

Typically, there are two ways it turns on. One of them is the switch you push; like many functions on the car, that sends a request to a module to make something happen. In this case, the HVAC controller tells the PCM that you want AC, and if it’s appropriate, it’ll give it to you.

The other way is if you set the controls to defrost. Since clearing the windshield is aided by removing moisture, and since that’s one thing that AC does, all vehicles that I’m aware of that have AC typically turn it on when the vent control is set to defrost. Once again, the HVAC controller tells the PCM what it wants, and the PCM does it if it’s appropriate.

There are a few reason why it might not let you have AC. One is that the system is empty of freon; most modern cars have one or more pressure sensors in the system, and if it’s too low or too high, it won’t let you have AC.

Too much engine load, for whatever reason, could block the AC request. I’ve seen that before on a Suburban that was idling so low that to turn on the AC would stall the engine. The truck knew that, so it wouldn’t allow the AC compressor to turn on.

Another reason would be that it’s inappropriate. If, for some reason, you decided to turn the AC on max when it was below freezing outside, the car wouldn’t bother with AC since it can’t make the air coming through the vents colder than it already is.


Source

Finally, another likely cause would be some part of the drivetrain is overtemperature (engine or transmission), or the cooling fans can’t be controlled properly. In order to make cold inside the cabin, the AC system has to make hot in the engine compartment, and if it can’t shed that heat, pressures go really high and then things get interesting. The pressure relief valve on an AC system opening is loud and very messy, and it’s best to avoid it.

Once the system is operating, depending on the vehicle, there are various inputs which help control it. Very simply, the more load on the engine, the less fuel mileage you get, so designers want to keep the engine load down whenever they can. External temperature sensors, sunload sensors, in-cabin temperature sensors, evaporator temperature sensors, and various other devices are used, depending on the complexity of the system.

If your eyes glazed over there just a bit, our Caravan has a reasonably simple system, most of which can be monitored from an aftermarket scan tool.

Most.


Now that I’d been given the keys to the vehicle (literally), I wanted to do some initial checks of my own. It wasn’t that I didn’t mistrust my manager’s initial diagnosis, but I’m more familiar with these things than he is.

One of the first things to look for, if you can, is if the vehicle saw the AC request. Usually, that’s a data line that’s either yes or no. In this case, it was yes.

Then you see if the PCM wants to turn the AC on, which is another yes/no.

In this case, it was no.

So we already know several somethings. We know that the PCM knows that the AC has been requested, and we also know that the PCM isn’t allowing it to be turned on.

One thing that would be nice is if the scan tool said why, but that information is rarely given. Over the last decade, some of that has been added; for example, on many GM vehicles, they’ll tell you why the cruise control turned off the last ten times. Really handy for diagnosing cruise control complaints.

We don’t get that for the AC.

Just for giggles, I decided to make sure that the PCM could actually control the AC compressor. You’d think if it couldn’t, it would throw a code, but they don’t always. So I went into the functional tests screen, selected the AC compressor, and it worked.


Source

Which was odd, because my manager had said that it didn’t.

[Rather than rely on you remembering this later when I give the reveal, I’ll tell you right now that he ran the test wrong. He didn’t know that on these Chryslers, you can only run this test when the engine is off. He did it with the engine running, like you would on GM, and the vehicle simply ignored him.]

This verified a few things for me. The PCM was capable of seeing an AC request and acting on it. That meant that something was blocking it. Something that wouldn’t set a code, which likely meant it wasn’t actually a malfunction, but a deliberate thing.

This was also something I’d seen on Chrysler minivans before.

Remember that outside air temperature sensor I mentioned before? The one that won’t let the AC work if it’s too cold, because why bother with AC when it’s cold? And--I didn’t tell you this--but if the circuit’s open, it defaults to -40 (F or C, take your pick).

“But wait, Admiral,” you’re saying, because you’ve read lots of these. “Surely the computer knows that’s wrong. After the vehicle has been sitting for a period of time, it can compare the engine coolant temperature sensor and the intake air temperature sensor and the transmission fluid temperature sensor with the ambient air temperature sensor, and know that the odd man out has failed.”

And of course, you’re right. It can, and it does.

But.

Here’s the sneaky thing.

Lots of components that aren’t critical to engine functionality or aren’t expected to have to react rapidly just communicate with the physically closest module, which then sends the info on either a low or high speed bus to the modules which might care to have that information. The ambient air temperature sensor, which is located in the grille on the front bumper, is physically closest to the smart fuse box, so that’s who gets that information.

Now, you’d be right to imagine that the smart fuse box can report that something isn’t right with this sensor. I have no idea if it does or doesn’t, because the Snap On scan tool can’t communicate with that module. The last one I diagnosed with a malfunctioning OAT sensor was when we were testing out the Autel scan tool, which could.

However, as it happens, there’s a second module who sees this information, and I don’t even need a scan tool to determine what it’s seeing. The overhead computer displays outside temperature, which it gets from that very sensor, and in fact on this van, it was correct.

So there went that theory.


In fact, every single thing I monitored in the HVAC module was sensible, and indicated no reason why the AC might not work.


Source

The next thing we did was recharge the system, and I’m glad we did. It turned out to be undercharged, and while that didn’t fix its control problem, it gave us confidence that if we were to figure out what was blocking the AC, the system would turn on and function normally.

My next stop was Identifix. I typed in the symptoms--no AC--and started reading the results. Most of them weren’t helpful; most of them were things I’d already looked at and rejected. But there was one item that showed up on the list that I hadn’t checked, the evaporator temperature sensor.

The primary purpose of this would be to ensure that the evaporator wasn’t too cold--if it was, ice could accumulate, blocking airflow, and you wouldn’t get AC until the ice melted. Sure, it would be super-frigid in the depths of the HVAC plenum, but that only provides comfort to the mouse who’s made a nest on top of the cabin air filter.*

That knocked some gears loose in my brain. There was a data PID for that, and I hadn’t paid it much attention.

Well, it looked normal at first, but then when I started graphing it, things got weird. It said the temperature was okay, but the voltage was probably too low for that to be a normal value.

____________________________________________
*generally, the cabin air filter is before the evaporator, so the mouse wouldn’t actually get any cooling, either.


Most sensors on a vehicle operate on a 5 volt scale, and most of them only have valid values between 0.5V and 4.5V. Chopping off the high and low end is for reliability, it makes up for poor connections and the like. The evaporator temperature sensor was reading 0.03V, which is unlikely to be a valid reading.

More importantly, it’s not a sensible reading. Since the point of this thing is to make sure that the evaporator doesn’t freeze, one end of its scale should be somewhere around the freezing point, and the other end of its scale ought to be about as hot as Chrysler thinks this thing is likely to get. No matter what, the 70 degrees (F) it was displaying on the scan tool didn’t correlate with 0.03V. If I assume that this sensor is one of the exceptions to the half-volt buffer, I’d assume that 0V should either be as low as the sensor can read, or as high as it can read, and 70F shouldn’t be either of those values.

What I think is that the scan tool is showing me a generated value. The computer doesn’t know what the sensor is telling it, so it’s programmed to stuff in a default number and work with that.

Admittedly, that doesn’t entirely make sense, either; 70F should allow the AC to operate.

While the vehicle was running, the voltage jumped all over the place with no rhyme or reason. And when we manually operated the AC for short periods of time (using a jumper relay) it was no more reliable. Both the voltage and the temperature value on the scan tool changed randomly, and not always sensibly (if the air temperature coming out of the vent is 50F, I know that the evaporator can’t be hotter than that, because that’s not how physics works).

So we ordered one, and when it arrived, we just plugged it in to see what would happen. Which, incidentally, is less fun than it sounds.


Source

You’re supposed to remove the instrument panel to gain access to this little guy, ‘cause it’s basically directly behind the radio, under the dash pad. However, it turns out that with a little bit of ingenuity, a 90 degree drill, a boroscope, and a willingness to jam your arm into a tiny space without complete assurance you’ll get it back, you can change it without taking the instrument panel all the way out. Plus, now that we know where it is, and where wood blocks need to be wedged into the dash cover for clearance, we can change the next one quicker.


You’ll be happy to know that the AC worked perfectly after installing the new sensor, although I still wasn’t entirely happy with how the voltage displayed on the scan tool. The temperature graph looked just like you’d expect it to--it went from ambient air temperature down to about 40F when the AC was running.

The voltage graph did not please me, however. It went from about one volt down to about 0.5V, and then jumped up to 4.5V, whereupon it went down to around 4V.

I have no idea if that’s a malfunction in the scan tool, or if that’s actually how that temperature sensor is supposed to work for some odd reason, and I wasn’t curious enough to pull the dash partially apart to measure it myself with a multimeter. The point was that we’d made the PCM happy, and in a lot of cases, that’s what a repair is actually about.


So what’s the moral to this story? I dunno. Sometimes computers do things without telling you they’re doing them, and sometimes even a very expensive scan tool can’t provide you with all the information you wish you had. Sometimes you’ve just got to rely on experience to see something that doesn’t look right.


Source


Also, I decided today that I’m not gonna leave y’all with a pony pic as an outro (although the face smashy anonfilly is an appropriate way to end).

No, today, y’all get MUSIC.

Crank it to eleven for maximum effectiveness.
